Varix™ Chiller

Description

By combining the benefits of chiller and VRF technology, Varix Chiller systems provide performance, efficiency and incredible space savings. The Varix Chiller heat pump is ideally suited for a wide range of applications, such as K-12 schools, multi-family buildings, industrial process systems, data centers, telecom centers, hospitality, growth facilities, emergency replacements, and others. The Varix Chiller heat pump has been optimized to provide maximum efficiency and performance utilizing R-32 refrigerant.

Product Features

  • 208/230V, 60 Hz / 3 Ph or 460V, 60 Hz, 3 Ph
  • 10 and 15 ton modules
  • Connect up to 16 units for up to 240 tons
  • Outdoor unit static pressure up to 0.32” WC
  • Standard, rotation and efficiency modes
  • Easily combine and fit multiple units even when space is limited
  • Optional kits available to integrate third-party fan coil units to central and local controls
  • Delivers water at a wide range of temperatures
  •  Cooling: 41°F - 77°F (5°C – 25°C) standard, 14°F – 77°F (-10°C – 25°C) with brine solutions
  • Heating: 77°F - 131°F (25°C - 55°C)*
  • High efficiency with full load efficiencies over 11.5 and part load IPLV’s over 21.5
  • Compact design with small footprint and weight. Module dimensions are 5’-10” long by 2’-7” wide by 5’-6” high. Unit weight is 1,008 lbs per module
  • Air cooled design eliminates the condenser water system and cooling tower. Eliminates the need for water treatment, cooling tower maintenance, and fresh water usage
  • Advanced control system provides precise and efficient control of the chiller heat pump system. A wealth of information is provided to system operators. BACnet interface is available to integrate the Varix Chiller into the building’s control system allowing seamless control and status information
